Terminal WebSocket System

The terminal system provides interactive PTY sessions inside Docker containers or directly on the host machine, accessible via a WebSocket connection at GET /api/ws/terminal.

Related docs: HTTP API | Events System

WebSocket Protocol

The terminal WebSocket uses a bidirectional JSON-based control protocol layered on top of the standard WebSocket framing:

• Client to server: JSON text frames (control messages)
• Server to client: JSON text frames (status messages) and binary frames (terminal output)

The WebSocket upgrader accepts all origins (CheckOrigin returns true).

Client-to-Server Messages

All messages are JSON objects with a type field that determines the operation.

create

Create a new terminal session. Detaches any currently attached session first.

{
  "type": "create",
  "container_id": "abc123def",
  "channel_id": "chan_001",
  "cmd": ["/bin/bash", "-l"],
  "target": "host",
  "rows": 24,
  "cols": 80,
  "open_mode": "fork"
}

Agent target behavior:

• If container_id is empty and channel_id is provided, resolves the container via ContainerFinder.FindContainerByChannel.
• Looks up the channel’s dir_path and session_id from the database.
• open_mode selects how the channel’s stored Claude session is consumed when launching the interactive command:
  • "resume" — resume the channel session in place (no fork). Falls back to a fresh session if the channel has no session_id.
  • "fork" — resume the channel session with the fork flag, so the new run gets its own session id. Auto-disabled (treated as "resume") when the channel has no session_id.
  • "fresh" — ignore the stored session_id entirely; Claude starts a new conversation.
  • Empty / missing — preserves the legacy behavior: threads that share the parent’s session set the fork flag automatically; channels resume in place.
• When no explicit cmd is given and a cmdBuilder is configured, sends the interactive Claude command as shell input after session creation.
• Maximum of 64 command arguments; empty arguments are rejected.

Host target behavior:

• Resolves the working directory from the channel’s dir_path. Falls back to parent channel’s dir_path for threads, then to ~/.loop/{channel_id}/work, and finally to $HOME.
• Default shell: $SHELL env var, then /bin/zsh if available, then /bin/sh. On Windows: $COMSPEC, then powershell.exe, then cmd.exe.
• Default shell arguments: -l (login shell) on Unix; none on Windows.

attach

Re-attach to an existing session. Provides ring buffer history replay.

{
  "type": "attach",
  "session_id": "a1b2c3d4"
}

Behavior:

• Detaches any currently attached session first.
• Tries the agent manager first; if that fails or is nil, tries the host manager.
• On success, replays the ring buffer contents as binary output before streaming live output.

input

Send user input to the active terminal session.

{
  "type": "input",
  "data": "bHMgLWxhCg=="
}

Errors: Returns no_session if no active session; invalid_input if base64 decoding fails.

Client keybindings (xterm.js renderer):

• Shift+Enter in agent and host shell panes emits \<CR> (backslash + carriage return) via input instead of a plain \r. This matches Claude Code’s /terminal-setup iTerm2 binding and bash readline line continuation, letting users compose multi-line prompts without submitting. A bare Enter still submits.
• Clicked URLs (via the xterm WebLinksAddon) route through window.loopAPI.openExternal in Electron, which calls shell.openExternal on the main process and opens the link in the OS default browser only. In a plain web browser, links fall back to window.open(url, "_blank", "noopener,noreferrer"). The Electron main process also denies about:blank and non-http(s) popups via setWindowOpenHandler, so links never spawn an in-app Loop window.

resize

Resize the PTY of the active session.

{
  "type": "resize",
  "rows": 40,
  "cols": 120
}

Errors: Returns no_session if no active session; missing_field if rows or cols is 0.

stop

Stop the active session and remove its container (agent sessions only). Used when shutting down a channel’s terminal entirely.

{
  "type": "stop",
  "session_id": "a1b2c3d4"
}

Behavior:

• Calls StopSession on the appropriate manager to close the exec connection.
• For agent sessions, removes the container via ContainerStopper.ContainerRemove so the channel list API reflects the updated state.
• For host sessions, skips container removal.

close

Close the exec session without removing the container. Used when closing an individual terminal pane while keeping the container alive.

{
  "type": "close",
  "session_id": "a1b2c3d4"
}

Response: Sends a stopped status message.

kill

Remove the container for a channel without requiring an active terminal session. Used when the terminal panel is closed and no panes are open.

{
  "type": "kill",
  "channel_id": "chan_001"
}

Behavior:

• If there is an active agent session, stops it first.
• Resolves the channel to a container via ContainerFinder and removes it.
• If no container is found, still reports success.
• Suppresses “already in progress” errors from concurrent removal.

Server-to-Client Messages

Status Messages (JSON text frames)

{
  "type": "created",
  "session_id": "a1b2c3d4",
  "message": "",
  "error_code": ""
}

Terminal Output (binary frames)

Raw PTY output is sent as WebSocket binary frames. The client should render these bytes in a terminal emulator (e.g., xterm.js).

Error Codes

Session Lifecycle

create ──> readLoop starts ──> fan-out to attached clients
                                    │
                              WS disconnect
                                    │
                              detachCurrent()
                              (session survives)
                                    │
                              WS reconnect
                                    │
                              attach ──> replay ring buffer ──> resume streaming
                                    │
                              explicit close/stop
                                    │
                              StopSession() ──> exec connection closed
                                              ──> all client channels closed
                                              ──> session removed from registry

1. Create: A new Docker exec (or host PTY) is started with a TTY. The session is registered in the manager and a read loop goroutine begins.
2. Read loop: Reads from the exec connection in 4096-byte chunks. Each chunk is written to the ring buffer and fanned out to all attached client channels (buffered, capacity 64). Slow consumers have output dropped with a warning log.
3. Attach: Registers a new client channel on the session. The ring buffer contents are replayed immediately, followed by live output streaming.
4. Detach on WS close: When the WebSocket disconnects, the session is detached (not stopped). The exec process and ring buffer continue running so the session can be reattached later.
5. Reattach: A new WebSocket connection can attach to the same session ID. The ring buffer provides the scrollback history.
6. Kill on explicit close: Only stop, close, or kill messages terminate the exec process. StopSession closes the exec connection, closes all client channels, and removes the session from the manager.

Docker Exec Sessions

Managed by DockerExecClient which wraps the Docker SDK exec API.

• ExecCreate: Creates an exec process inside a running container with Tty: true, stdin/stdout/stderr attached. Runs as the host user ($USER env var) matching the container’s non-root agent user. Default command is /bin/sh.
• ExecAttach: Attaches to the exec process and returns an io.ReadWriteCloser wrapping the Docker HijackedResponse. Reads use the buffered reader; writes go to the underlying connection.
• ExecResize: Changes PTY dimensions via the Docker exec resize API.

The hijackedConn adapter wraps the Docker SDK’s HijackedResponse as a standard io.ReadWriteCloser.

Host PTY Sessions

Managed by HostExecClient which runs shell processes directly on the host machine.

Unix (Darwin/Linux)

Uses creack/pty to start processes with a pseudo-terminal:

• ExecCreate: Prepares the command with Setsid: true (new process group). Validates the command via exec.LookPath.
• ExecAttach: Starts the process via pty.Start and returns a hostPTYConn wrapping the PTY file descriptor.
• ExecResize: Uses pty.Setsize to change the PTY window size.
• Cleanup (hostPTYConn.Close):
  1. Sends SIGHUP to the process group (syscall.Kill(-pid, SIGHUP))
  2. Waits up to 3 seconds for the process to exit
  3. If still running, sends SIGKILL to the process group
  4. Closes the PTY file descriptor
  5. Uses sync.Once to ensure cleanup runs exactly once

Windows

Uses UserExistsError/conpty for Windows ConPTY support:

• ExecCreate: Builds a command line string with proper quoting. Validates via exec.LookPath.
• ExecAttach: Starts the process via conpty.Start with working directory and environment options. Requires Windows 10 1809+.
• ExecResize: Uses conpty.Resize(width, height) (note: width before height).
• Cleanup (hostConPTYConn.Close): Calls conpty.Close with sync.Once.

Ring Buffer

RingBuffer is a fixed-size circular byte buffer used for terminal scrollback. Default size is 1 MB (1,048,576 bytes).

• Thread-safe: All operations are protected by a sync.Mutex.
• Circular writes: When full, new data overwrites the oldest bytes. The write position wraps around.
• History replay: Bytes() returns all buffered data in chronological order, handling the wrap-around case.
• Methods: Write(p []byte), Bytes() []byte, Len() int, Reset().

When data larger than the buffer is written, only the last size bytes are kept.

Session Registry

Sessions are stored in a map[string]*Session within the Manager, keyed by randomly generated 8-character hex IDs (4 random bytes).

The ManagerAdapter bridges the internal terminal.Manager to the api.TerminalManager interface:

• CreateSession creates the session, immediately attaches a client channel, and returns all fields decomposed.
• AttachSession re-attaches to an existing session and returns the output channel, history, and done channel.
• DetachSession, SendInput, Resize, StopSession delegate directly.

Agent vs Host Terminal Differences

Container Ensurer

The ContainerFinder interface resolves a channel_id (and optional dir_path) to a running Docker container ID. This allows the terminal handler to create sessions by channel rather than requiring the client to know the container ID.

The ContainerStopper interface removes containers by ID, used during stop and kill operations.

Idle Timeout

Sessions can be configured with an idle timeout via Manager.SetIdleTimeout. When set, a timer resets on each output read. If no output is received within the timeout duration, the session automatically closes by closing the exec connection.
